Engine Specification

Cylinder displacement                                            38.2cc

Power output                                                          2 hp

Maximum power speed                                          9000rpm

Idling Speed                                                            3000rpm

Spark plug                                                              Champion     RCJ7Y

Electrode gap                                                         0.02

Lubricants

Oil tank volume                                                       0.09 US pint

Oil pump type                                                          Fixed flow

Oil pump capacity                                                    8-8ml/min

Vibration & noise data

Equivalent vibration level (ahv, eq)                          front/2.1/2.7 m/g2 rear handle

Sound pressure level at operators ear                   100.7dB(A)

Sound power level,guaranteed (LWA)                    113dB(A)

Cutting Equipment

Chain pitch                                                              .325"/3/8"

Recommended bar length,min-max                       13" -16"

Chain speed at max power                                     53.48fts

Overall dimensions

Weight (excl. cutting equipment)                            10.3lbs

Air Injection

Centrifugal air cleaning system removes larger dust and debris particles before reaching the air filter. This results in reduced air filter cleanings and improved engine life.



Air Purge

Removes air from carburetor and fuel system for easy starting.

Combined Choke/Stop Control

Allows for easier starting and reduces the risk of engine flooding.



Inertia

Reduces likelihood of injury due to kickback.

Low Vibe

System designed to reduce vibration levels to the operator, which lessens fatigue.

Side-mounted chain tensioner

Easier access to chain tensioning device.
